1.        6521 polyester film/insulation paper composite material  is made of electrical insulation paper and polyester film layer formed by adhesive bonding composite materials,heat level E grade.This material has a excellent performance in both electrical and mechanical properties.

2.        Application:

3.        It is widly used for small motor and electrical insulation slot liner, gasket and turn to turn and layer insulation,liner insulation,transformer insulation,and other electrical insulation with termperature requirement not exceeding 130,

4.        Certification:ISO Quality certification;SGS System Certification;Electrical machinery industry by product quality supervision and inspection center material testing.

5.        Colour:Brown

6.        Thickness:0.15mm-0.60mm  Width:1000mm

7.        Form: Roll; Sheet; Strips

※Note: The values noted in below technical specification are given only for our customers’ reference and should not be used in writing specifications.
